Chicago Pneumatic CP3019-20AF Super Duty Angle Sander 75mm Pad 20000 Rpm


Features & Benefits:

  • Highly durable bevel gear
  • Compact body
  • Insulating composite over housing
  • Streamlined safety lever
  • Rear exhaust3" (76 mm) roloc plate capacity
  • 0.5 hp (375 W) governed motor
  • 20,000 rpm free speed
  • Ergonomic handle and high speed
  • Highest durability in demanding applications up to 2,000 hours maintenance intervals


Specifications:

  • Model: CP3019-20AF
  • Part Number: 6151607090
  • Actual Air Consumption: 342 l/mn / 12.084 cfm
  • Air Inlet Thread Size: 1/4"
  • Average Air Consumption: 171 l/mn / 6.042 cfm
  • Box Dimensions: 353x173x63mm
  • Free Speed: 20000 rpm
  • Free Speed Air Consumption: 9.3 l/s / 19.716 cfm
  • Length: 166mm / 6.3"
  • Min. Hose Size: 8mm / 3/8"
  • Net Weight: 0.635 kg / 0.29 lb
  • Pad Diameter: 75mm / 3"
  • Paper Size: 50mm / 2"
  • Power: 375 W / 1/2 hp
  • Sound Power: 92.6 db(A)
  • Sound Pressure: 81.6 db(A)
  • Spindle Thread: 1/4"-20 UNC
  • Vibration: 2.7 m/s²
  • Vibration ISO: ISO-28927-3
  • Vibration Uncertainty (K): 1.3 m/s²

(CP3019-20AF)

Brand Chicago Pneumatic
Shipping Cubic 0.001660000m3
